2U Server Rack Blanking Panel 19 Inch EIA 310 CAD model
Professional, high-precision 3D CAD model and PBR asset of a standard 2U 19-inch Server Rack Blanking Panel.
Engineered strictly according to EIA-310-D / IEC 60297 standards, this model was designed in FreeCAD based on official technical drawings. It is 100% production-ready for sheet metal fabrication, laser cutting, CNC bending, as well as high-end 3D visualization and simulation.
==================================================
1. MANUFACTURING & ENGINEERING DETAILS
==================================================
- Modeled in FreeCAD: Designed with precise parametric sheet metal features and exact hole placement.
- Factory-Ready CAD Files: The included STEP, IGES, and DXF files can be directly sent to sheet metal manufacturing, laser cutters, CNC punch presses, or bending machines.
- Real-World Scale (1:1): Exact physical dimensions (487.6 mm x 76.2 mm x 1.5 mm thickness).
- EIA-310 / 19" Rack Compliant: Fits perfectly into any standard server cabinet, network rack, or home lab enclosure.
==================================================
2. VISUALIZATION & MESH SPECIFICATIONS
==================================================
- Dual Purpose: Includes both CAD vector models (STEP/IGES/DXF) and optimized 3D polygonal meshes (BLEND/FBX/OBJ/STL).
- Clean Topology: Properly unwrapped UVs with non-overlapping layout.
- 2 Material/Color Variations:
1. Matte Black Powder-Coated Finish (Industrial Data Center standard).
2. Brushed Stainless Steel / Light Anodized Metal.
- Render Setup: Configured for both Eevee and Cycles render engines in Blender.
==================================================
3. TECHNICAL SPECIFICATIONS
==================================================
- Panel Height: 2U (76.2 mm / 3.0 inches)
- Panel Width: 19 Inches (487.6 mm)
- Sheet Metal Thickness: 1.5 mm
- Standard Mounting Hole Pitch: Fits M6 rack screws / cage nuts.
==================================================
4. INCLUDED FILE FORMATS
==================================================
CAD & Manufacturing Formats:
• STEP (.step / .stp) — Universal CAD standard for CNC and factory fabrication.
• IGES (.iges / .igs) — High-precision surface CAD format.
• DXF (.dxf) — 2D/3D vector profile for laser/plasma cutting.
3D & Exchange Formats:
• BLEND (.blend) — Native Blender file with materials & node setups.
• FBX (.fbx) — High-compatibility exchange format for game engines & 3D software.
• OBJ (.obj + .mtl) — Universal 3D geometry file.
• STL (.stl) — Ready for 3D printing and quick prototyping.
==================================================
5. RECOMMENDED USES
==================================================
• Sheet Metal Production & CNC Manufacturing
• Server Room & Data Center 3D Layouts
• Industrial Design & Engineering Presentations
• Photorealistic Architectural & IT Renders
• VR/AR Simulations and Game Environments
