Hellboy Model Printing Assembly

3D Render by Cody3D

YOUTUBE Video: https://www.youtube.com/watch?v=oMFX8EP__jQ&t=59s
follow me
FACEBOOK: https://www.facebook.com/groups/1797954133626126/?ref=bookmarks
ISTAGRAM: cody3d1 https://www.instagram.com/cody3d1/
TWITTER: https://twitter.com/Cody3D
ARTSTATION: https://www.artstation.com/cody3d

STL file optimized for FDM-FFF DLP-SLA-SLS printing

Hellboy 3D Model
figurine, Miniature Assembly Figure
more than 200 hours of modeling
two versions, long and short horns
however, the dimensions can be changed with each slicer

in total HellBoy and composed of 4,178 mil points
all the files have been decimated by the polygons, but without losing the details, this makes the light files suitable for each computer

1:8 for FDM-FFF, 1:14 for DLP-SLA-SLS

dimensions approximately FDM-FFF Z 31Cm X 12.5Cm Y 15Cm
Z 11.8inch X 4.9inch Y 5.9inch

dimensions approximately DLP-SLA-SLS Z 13Cm X 6.9Cm Y 7.1Cm
Z 5.1inch X 2.7inch Y 2.8inch

all files are already in place for optimal printing

HellBoy 3D model was designed to get a clean print result, without considering printing material consumption, However, you are free to rotate, or scale,
every part of the model in the most convenient way for you.
Each file has been checked and repaired with Netfabb
The parts of the model are already positioned for 3D printing
Compatible with every Slicer- Simplify3D, Care, Slic3r, etc ...
All the parts of the model have been cut so as to be printed vertically, for a higher quality of printing

Recommended settings for printing

each part was cut to be printed vertically, to have a better quality print, so for the upper parts,

it is recommended to print with a 4-5 skirt

Quality

Layer height: 0.1mm*

Initial layer thickness: 0.3mm

Bottom/top pattern: lines

Skin perimeter line count: 0

Horizontal expansion: 0.04mm (when entering 0.04mm index, the 3D printer perceives the model as monolith, i.e. as having no hidden layers).

*Layer Height 0.1mm is recommended for a better quality for the printed model. However, the printing time will double.

As a STL file provider, our goal is to ensure that the files are error-free and printable in the most accurate way. This is why we only test print the most difficult segments of

the model’s parts.

Speed setups:

Infill speed: 30mm/s

Outer shell speed : 30mm/s

Inner shell speed: 20mm/s

Top/bottom speed: 20mm/s

Support speed: 50mm/s

Travel speed: 150mm/s

Skirt speed: 30mm/s

Amount of slower layers: 4

Infill:

Infill pattern: Grid
